Fuel System
Service Chart
131
7
2-Cylinder Models: Reed Plate Assembly and Throttle Body
25-35 in. lbs
(2.8-3.5 n·m)
002474
60-120 in. lbs
(7-14 n·m)
10-14 in. lbs
(1.1-1.6 n·m)
10-14 in. lbs
(1.1-1.6 n·m)
60-120 in. lbs
(7-14 n·m)
10-18 in. lbs
(1.1-2.0 n·m)
IMPORTANT: Do NOT lubricate TPS
to throttle shaft surface.
A Triple-Guard Grease
B Gasket Sealing Compound
C Adhesive 847
D Moly Lube
E Red Ultra Lock
F Blue Nut Lock
G Needle Bearing Grease
X see Service Manual
