Oiling System
Oil Component Servicing
178
IMPORTANT: Be sure oil pick up assembly is po-
sitioned in front of oil tank baffle to prevent inter-
ference with the LOW OIL switch.
All Models
Install oil pump retainer screw(s). Tighten
securely.
IMPORTANT: Turn self-tapping screws counter
clock-wise to start the threads and clockwise to
tighten. Failure to follow this procedure can dam-
age the threads of the oil tank.
1. Oil pick up assembly
2. Oil tank baffle
008183
