BRP E-TEC EVINRUDE - Page 247

Midsection
Service Charts
247
11
Tiller Handle (Long)
18-20 Ft. lbs.
(24.5-27 N·m)
18-20 Ft. lbs.
(24.5-27 N·m)
18-20 Ft. lbs.
(24.5-27 N·m)
60-84 In. lbs.
(7-9.5 N·m)
18-20 Ft. lbs.
(24.5-27 N·m)
20-30 In. lbs.
(2.3-3.4 N·m)
36-48 In. lbs.
(4-5.4 N·m)
A
36-40 Ft. lbs.
(49-54 N·m)
F
18-20 Ft. lbs.
(24.5-27 N·m)
24-36 In. lbs.
(2.7-4 N·m)
F
F
A
A
D
D
010311
Steering Friction Device
Optional on 2-Cylinder Models
A Triple-Guard Grease D Moly Lube F Blue Nut Lock
