51
Routine Service
Storage
2
Software Control Method
Winterization can also be run using Evinrude
Diagnostics software. With the outboard running,
start the process at the Settings/Adjustments
screen and follow the instructions.
After the outboard shuts itself off, turn key switch
OFF, then detach garden hose.
IMPORTANT: When finished, leave the outboard
in vertical position long enough to completely drain
the powerhead.
Additional Recommendations
• Fill oil reservoir.
• Inspect the fuel filter. If there is debris in the fuel
filter, it must be replaced.
• Replace gearcase lubricant.
• Remove and inspect propeller.
• Clean and grease propeller shaft.
• Blow water from gearcase speedometer pickup
system (gearcase speedometer models only).
• Lubricate all grease fittings and linkages.
• Inspect outboard, steering system, and con-
trols. Replace all damaged and worn compo-
nents. Refer to manufacturer’s and lubrication
recommendations.
• Touch up painted surfaces as needed. Coat
outer painted surfaces with automotive wax.
• Remove battery(s) from boat. Store in a cool,
dry location. Periodically charge battery(s) while
stored. Refer to manufacturer’s maintenance
recommendations when servicing batteries.
• Store outboard in upright (vertical) position.
• Check for fuel leakage.
1. Winterization start button
008564
008565
WARNING
Failure to check for fuel leakage could allow a
leak to go undetected, resulting in fire or
explosion.
