BRP E-TEC EVINRUDE - Page 95

Electrical and Ignition
Service Charts
95
6
60 to 84 in. lbs.
(7 to 9.5 N·m)
7 to 10 in. lbs.
(0.8 to 1.1 N·m)
24 to 36 in lbs.
(2.7 to 4 N·m)
60 to 84 in lbs.
(7 to 9.5 N·m)
F
30 to 42 in lbs.
(3.4 to 4.8 N·m)
24 to 36 in lbs.
2.7 to 4 N·m)
B
X
15 to 30 ft. lbs.
(20 to 41 N·m)
Z
002249
A Triple-Guard Grease
B Gasket Sealing Compound
C Adhesive 847
D Moly Lube
E Red Ultra Lock
F Blue Nut Lock
T Liquid Neoprene
X See Service Manual Text
Z Thermal Joint Compound
