2-30 2002 Buell P3: Chassis
HOME
11WARNING1WARNING
Check for proper brake lamp operation before riding
motorcycle. Visibility is a major concern for motorcy-
clists. Failure to have proper brake lamp could result in
death or serious injury.
8. Turn ignition key switch to IGN. Apply rear brake pedal to
test brake lamp operation. Turn ignition key switch to
LOCK.
11WARNING1WARNING
Always test motorcycle brakes at low speed after servic-
ing or bleeding system. If brakes are not operating prop-
erly, or braking efficiency is poor, testing at high speeds
could result in death or serious injury.
Figure 2-45. Remote Reservoir
Figure 2-46. Master Cylinder Internals
7703
6506
1
2
3
4
1. Master Cylinder Body
2. Snap Ring
3. Rod Assembly
4. Piston Assembly
