2002 Buell P3: Chassis 2-61
HOME
WINDSCREEN 2.26
REMOVAL
1. See Figure 2-103. Remove two screws and nylon wash-
ers on each side.
2. Remove windscreen.
3. See Figure 2-104. Remove windscreen trim.
4. Remove windscreen mounting brackets.
INSTALLATION
1. If removed, install both windscreen brackets. See 7.17
HEADLAMP.
2. Verify trim is installed on windscreen.
3. Install two screws and nylon washers on each side.
Tighten screws to 9-11 in-lbs (1 Nm).
Figure 2-103. Remove Screws
Figure 2-104. Windscreen Trim
3779
3797
