ELECTRICAL CONNECTORS B.1
GENERAL
The following table provides a description of the connectors
found on your motorcycle.
Connector numbers are listed in [brackets] in this manual.
NOTE
Male ends of connectors are labeled “A” in text.
Female ends of connectors are labeled “B” in text.
Table B-1. Electrical Connectors
CONNECTOR
DESCRIPTION COMPONENT(S) LOCATION
[7] 6-place Amp Multilock Tail Lamp/Rear Directionals Under Seat
[10] 6-place Deutsch Integrated Ignition Module Sensor
Left side of frame backbone on
T-stud
[22] 4-place Amp Multilock
Right Handlebar Switch Housing-
ignition power, module and starter
Behind windscreen
[20] 12-place Deutsch Indicators/Speedometer Behind windscreen
[24]
10-place Amp Multilock Left Handlebar Switch Housing-
turn signals, lights
Behind windscreen
[30] 3-blade relay connector Flasher Relay Under seat, to right of battery
[33] 4-place Deutsch Ignition/Headlamp Key Switch Behind windscreen
[38] 4-place Amp Multilock Headlamp Behind windscreen/headlamp
[39] 12-place Packard Speedometer/Indicators On back of speedometer
[46] 2-place barrel connector Voltage Regulator Above swingarm, left side
[60]
2-place Amp Multilock Side Stand Switch On top of swingarm, cable tied to
rear brake line
[61] 9-slot fuse block Fuse Block Under seat on right side
[65] 3-place Deutsch Speed Sensor Under seat, to right of shock
[83] 3-place Amp Multilock Ignition Coil Under frame backbone at coil
[88]
6-place Deutsch Throttle Position Sensor and Auto-
Enrichener
Under frame backbone, right side
[95] 2-place Amp Multilock Clutch Switch At left handlebar
[120]
Post Oil Pressure Switch Above oil filter, right lower side of
crankcase
[121]
2 blades Rear Stoplight Switch At switch, under frame by shock
absorber
[122] Blade Horn At horn, behind front fork
[123] 4-blade relay connector Starter Relay Under seat to right of battery
[128] Blade Starter Under starter solenoid
[131] Post Neutral Switch Behind sprocket cover, right side
[134] 3-place Packard Bank Angle Sensor Under Seat to right of battery
[170] 2 blades Front Brake Switch At right handlebar switch
[171] 4-blade relay connector System Relay Under seat, to left of battery
[172] 1-Place Bullet Neutral Switch to main harness Above sprocket cover, right side
