FRONT FORK REMOVAL
1. Raise front wheel off floor.
2. Detach front brake caliper from rotor. See 2.11 FRONT
BRAKE CALIPER.
3. Remove front wheel. See 2.5 FRONT WHEEL.
4. Remove front fender. See 2.23 FENDERS.
5. See Figure 2-55. Loosen head lamp bracket screws.
6. See Figure 2-56. Loosen the large pinch screws on both
the upper and lower triple clamps.
7. See Figure 2-57. Remove front fork. Repeat procedure
for the other front fork.
Figure 2-55. Headlamp Brackets
Figure 2-56. Pinch Screws
Figure 2-57. Front Fork Removal
a0065aSx
Headlamp Bracket
Screws
3765
Upper
Triple
Clamp
Lower
Triple
Clamp
3766
