2-62 2002 Buell P3: Chassis
HOME
INSTRUMENT PANEL 2.27
REMOVAL
1. See Figure 2-105. Remove two mounting screws and
instrument panel.
2. Remove two screws from back of instrument panel.
3. Remove rubber boot and odometer reset switch.
4. Depress tab and remove speedometer connector [39].
NOTE
To remove speedometer, see 7.25 ELECTRONIC SPEED-
OMETER.
INSTALLATION
1. Install odometer reset switch to instrument panel and
install rubber boot.
2. Install connector [39] on back of speedometer.
3. Apply LOCTITE THREADLOCKER 243 (Blue) to threads
of mounting screws. Install dash with two mounting
screws. Tighten screws to 30-36 in-lbs (3-4 Nm).
Figure 2-105. Instrument Panel
a0154x2x
Screws (2)
Odometer Reset
Switch Rubber Boot
Odometer Reset
Switch
Connector [39]
30-36 in-lbs
(3-4 Nm)
