Buell 2002 P3 - Front Fork Installation

2-48 2002 Buell P3: Chassis
HOME
23. See Figure 2-85. Install slider tube cap.
FRONT FORK INSTALLATION
1. See Figure 2-86. Install fork tubes through upper and
lower triple clamps.
NOTE
When installing the front forks, use a screwdriver to pry apart
the triple clamps.
2. See Figure 2-87. Apply LOCTITE ANTI-SEIZE to the
threads of triple clamp pinch screws.
3. See Figure 2-88. Align and secure fork tubes.
Figure 2-85. Slider Tube Cap
Figure 2-86. Installing Fork Tube
Figure 2-87. Triple Clamp Pinch Screw
3768
3766
3777
Anti-Seize
