2002 Buell P3: Chassis 2-47
HOME
17. See Figure 2-83. Remove the tape from the slide pipe
end.
NOTE
The recommended fork oil is hydraulic fork oil type “E”.
18. Pour 9.2 oz. fork oil into fork.
19. Install lower spring seat and spring collar.
20. Coat a new O-ring with fork oil or sealing grease.
21. Install new O-ring onto spring seat.
22. See Figure 2-84. Push down on spring seat past groove
to install stopper ring. Stopper ring will lock into groove
when installed correctly.
Figure 2-82. Install New Dust Seal
Figure 2-83. Remove Slider Tube Protection
Figure 2-84. Compressing Spring Seat
3788
3781
3769
