2002 Buell P3: Electric Starter 5-1
HOME
SPECIFICATIONS 5.1
TORQUE VALUES
STARTER
Free Speed 3000 RPM (min.) @ 11.5 V
Free Current 90 amp (max.) @ 11.5 V
Stall Current 400 amp (max.) @ 2.4 V
Stall Torque 8.1 ft-lbs (11.0 Nm) (min.) @ 2.4 V
SERVICE
WEAR LIMITS
IN. MM
Brush Length minimum 0.433 11.0
Commutator Diameter
minimum
1.141 28.981
ITEM
TORQUE NOTES
Battery terminal bolts 60-96
in-lbs
7-11 Nm Page 5-18
Starter battery positive cable nut 80-100
in-lbs
9-11Nm Metric, Page 5-18
Starter mounting bolts 13-20 ft-lbs 18-27 Nm Page 5-18
5
