Buell 2002 P3 - 1.14 FRONT FORK OIL

1-24 2002 Buell P3: Maintenance
HOME
FRONT FORK OIL 1.14
GENERAL
Drain and refill the front forks with fresh fork oil:
● At every 20,000 mile (32,000 km) service interval.
FORK OIL CHANGE
1. Remove front forks. See 2.17 FRONT FORK.
2. See Figure 1-25. Clamp the fork in a vise with front fork
holding tool (part no. B-4177).
3. See Figure 1-26. Remove slider tube cap.
4. See Figure 1-27. Push down on the B-spring seat (O-
ring included) and remove the stopper ring and spring
seat.
Figure 1-25. Clamping the Fork
Figure 1-26. Slider Tube Cap
Figure 1-27. B-Spring Seat
3767
3768
3769
