2002 Buell P3: Maintenance 1-25
HOME
5. See Figure 1-28. Remove the spring collar, lower spring
seat and spring from slider tube.
6. See Figure 1-29. Remove the fork oil by pumping the
fork leg and rod 8-10 times until the rod moves freely.
NOTE
The recommended fork oil is hydraulic fork oil type “E”.
7. Pour 9.2 oz. fork oil into fork.
8. Install lower spring seat and spring collar.
9. Coat a new O-ring with fork oil or sealing grease.
10. Install new O-ring onto spring seat.
11. See Figure 1-30. Push down on spring seat past groove
to install stopper ring. Stopper ring will lock into groove
when installed correctly.
12. See Figure 1-31. Install slider tube cap.
13. Install front forks. See 2.17 FRONT FORK.
Figure 1-28. Removing Sub-Assembly
Figure 1-29. Pumping Fork Oil
1. Spring collar
2. Lower spring seat
3. Spring
a0006xSx
1
2
3
3770
Figure 1-30. Compressing Spring Seat
Figure 1-31. Slider Tube Cap
3769
3768
