2002 Buell P3: Electrical 7-1
HOME
SPECIFICATIONS 7.1
BATTERY
Rating 12 VDC/12AH/200CCA
Type Sealed
ALTERNATOR
AC Voltage Output 19-26 VAC per 1000 engine RPM
Stator Coil Resistance 0.2-0.4 Ohms
REGULATOR
Voltage Output @ 75°F 14.3-14.7 VDC
Amperes @ 3600 RPM 22 Amps
IGNITION TIMING SPARK OCCURRENCE
RPM
TP Sensor
Low Voltage
(PT)
High Voltage
(WOT)
1200 RPM (Idle) 20˚ BTDC 18˚ BTDC
3000 RPM 30˚ BTDC 18˚ BTDC
6000 RPM 45˚ BTDC 35˚ BTDC
Curve Switch Point TP Sensor Input 2.4V
Rev Limit 6500 RPM
IGNITION COIL RESISTANCE
Primary Winding 0.4-0.6 ohms
Secondary Winding 7,720-9,440 ohms
SPARK PLUG CABLE RESISTANCE
Spark Plug Cable 2,375-5,833 ohms
ELECTRICAL SYSTEM
AMPERES
Main Circuit Breaker 30
Ignition Fuse 7.5
Light Fuse 15
Accessory Fuse 7.5
System Fuse 15
Key Switch Fuse 15
LAMP DESCRIPTION
BULBS
REQUIRED
WATTS AMPS
PART
NUMBER
Headlamp High/Low 1 60/55 5.0/4.58 67713-86
Marker lamps
Tail/Stop Lamp 1 5/21 0.42/1.75 Y0401B.2U
Turn Signal Lamp, Front and Rear
(1 bulb each)
4100.83 68968-99Y
Indicator lamps
(in speedometer)
High Beam Indicator
Non-replacable LEDs
Turn Signal Indicator
Oil Pressure Indicator
Neutral Indicator
