HYDRAULIC LIFTER
NEW COMPONENTS SERVICE WEAR LIMITS
Fit in guide 0.0008-0.0020 in. 0.0203-0.0508 mm 0.0030 in. 0.0762 mm
Roller fit 0.0006-0.0010 in. 0.0152-0.0254 mm 0.0015 in. 0.0381 mm
Roller end clearance 0.008-0.022 in. 0.203-0.559 mm 0.026 in. 0.660 mm
OIL PUMP NEW COMPONENTS SERVICE WEAR LIMITS
Oil
pressure
1000 RPM 7-12 PSI 48-83 KPa
2500 RPM 10-17 PSI 69-117 KPa
Shaft to pump clearance 0.0025 in. 0.0635 mm
Feed/scavenge inner/outer
gerotor clearance
0.003 in. 0.076 mm 0.004 in. 0.102 mm
GEARCASE
NEW COMPONENTS SERVICE WEAR LIMITS
Cam gear shaft in
bushing (loose)
0.0007-0.0022 in. 0.0178-0.0559 mm 0.003 in. 0.076 mm
Cam gear shaft end play
(min)
0.005-0.024 in. 0.127-0.610 mm 0.025 in. 0.635 mm
Intake cam gear shaft end
play (min)
0.006-0.024 in. 0.152-0.610 mm 0.040 in. 1.016 mm
FLYWHEEL
NEW COMPONENTS SERVICE WEAR LIMITS
Runout
Flywheels at
rim
0.000-0.010 in. 0.000-0.254 mm 0.010 in. 0.254 mm
Shaft at
flywheel end
0.000-0.002 in. 0.000-0.051 mm 0.002 in. 0.051 mm
End play 0.001-0.005 in. 0.025-0.127 mm 0.005 in. 0.127 mm
SPROCKET SHAFT
BEARING
NEW COMPONENTS SERVICE WEAR LIMITS
Outer race fit in
crankcase (tight)
0.0004-0.0024 in. 0.0102-0.0610 mm
Bearing inner race fit
on shaft (tight)
0.0002-0.0015 in. 0.0051-0.0381 mm
PINION SHAFT BEARINGS NEW COMPONENTS SERVICE WEAR LIMITS
Pinion shaft journal diameter
1.2496-1.2500 in.
31.7398-31.7500
mm
1.2496 in. (min) 31.7398 mm (min)
Outer race diameter in
right crankcase
1.5646-1.5652 in.
39.7408-39.7561
mm
1.5672 in. (max) 39.8069 mm (max)
Bearing running clearance
0.00012-0.00088 in.
0.00305-0.02235
mm
Fit in cover bushing
(loose)
0.0023-0.0043 in. 0.0584-0.1092 mm 0.0050 in. 0.1270 mm
