3-28 2002 Buell P3: Engine
HOME
Rocker Arms and Bushings
1. See Figure 3-54. To replace worn bushings, press or
drive them from the rocker arm. If bushing is difficult to
remove, turn a 9/16-18 tap into bushing. From opposite
side of rocker arm, press out bushing and tap.
2. Press replacement bushing into rocker arm, flush with
arm end, and split portion of bushing towards top of arm.
3. Using remaining old bushing as a pilot, line ream new
bushing with ROCKER ARM BUSHING REAMER (Part
No. HD-94804-57).
4. Repeat for other end of rocker arm.
Figure 3-54. Removing Rocker Arm Bushing
9/16 in. -18 tap
2411a
