6-2 2002 Buell P3: Drive/Transmission
HOME
TORQUE VALUES
ITEM
TORQUE NOTES
Battery terminal bolts 60-96 in-lbs 7-11 Nm Page 6-6
Clutch inspection cover screws 7-9 ft-lbs 10-12 Nm Tighten crosswise pattern, Page 6-11
Clutch mainshaft nut 70-80 ft-lbs 95-109 Nm
LOCTITE® thread locker 262 (red), left hand threads,
Page 6-20
Crankcase 1/4 in. screws 180-100 in-lbs 9.0-12.4 Nm LOCTITE® thread locker 262 (red), Page 6-39
Crankcase 5/16 in. screws 15-19 ft-lbs 20-25 Nm LOCTITE® thread locker 262 (red), Page 6-39
Engine sprocket nut 190-210 ft-lbs 258-285 Nm LOCTITE® thread locker 262 (red), Page 6-20
Primary cover bolts 100-120 in-lbs 11-14 Nm Follow torque sequence, Page 6-6
Rear axel nut 48-52 ft-lbs 65-71 Nm Page 6-9
Retention collar screw 13-17 ft-lbs 18-23 Nm LOCTITE® thread locker 243 (blue), Page 6-41
Shift lever pinch fastener 12-14 ft-lbs 16-19 Nm Page 6-6
Shifter shaft assembly locknuts 90-110 in-lbs 10-12 Nm Bottom nut first, same torque for top, Page 6-41
Transmission drain plug 14-30 ft-lbs 19-54 Nm Remove debris from end, Page 6-10
Transmission sprocket nut See NOTES See NOTES
LOCTITE® thread locker 262 (red), left hand threads,
special torque turn method, Page 6-43
Transmission sprocket screws 90-110 in-lbs 10-12 Nm Replace after 3 removals, Page 6-44
