B - Barcode Add-On2
Barcode type: Add-on2 (EAN/UPC Addendum 2)
Length: fixed 2-digits
Valid characters: numeric only
check digits: no
ratio oriented: yes
Add-On2 is an addendum code which is used together with EAN or UPC barcodes.
Mainly used for magazines to diplay the magazine publication release (normally a
2 digit number of the week or month)
The size must fit to the printed size of the EAN or UPC code. We recommend to
use SC sizes with this barcode.
B[:name;]x,y,r,ADDON2[+options],height,ne;text CR
B - Barcode field definition
[:name;] = field name
x = x - coordinate
y = y - coordinate
r = Rotation 0, 90, 180 and 270 degrees
type = Barcode type (ADDON2)
[+options] Following options are available:
+WSarea = white space area
+BARS = Prints boundary lines above and below the barcode.
+UPBAR = Prints a boundary line above the barcode
+DOWNBAR = Prints a boundary line below the barcode
+VERIFYn = Verify the barcode data. (optional barcode reader required )
+GOODBADn = Same function as +VERIFYn without checking the content.
size = Standard Codesize SCx (instead of height and ne)
height = Barcode height
ne = Narrow element
text = Barcode data
Detailed descriptions are at the beginning of the barcode chapter.
Syntax:
