cab Produkttechnik GmbH & Co KG
[JOBID] print
JOB ID
The JOBID command prints the Identification of the print job. For further information please see also
"j Job-ID" and "ESC j".
[JOBID]
[JOBID]
- print Job ID
m m
J
O R
S l1;0,0,68,70,55
T 10,20,0,5,7;JOBID:
T 10,30,0,5,6;
[JOBID]
A 1
Example:
Syntax:
357
359
