cab Produkttechnik GmbH & Co KG
Example:
Mathematical Functions
[
|
:op1,op2]
Logical Or
m m
J
S l1;0,0,68,71,100
T:var1;25,10,0,3,5;0
T:var2;25,20,0,3,5;0
G 20,25,0;L:20,0.3
T:res;25,35.0,.0,3,5.0;
[|:var1,var2]
A1
Result 0, because both variables are 0.
