B - Barcode UPC-E0
Barcode type: UPC-E0
Length: fixed - 8 characters *
Valid characters: numeric
check digits: yes (Mod 16)
ratio oriented: yes
UPC-E0 is a numerical barcode with 8 characters. The 8th character is the check
digit. The check digit is calculated automatically by the printer.
Invalid characters are converted into zeroes.
* A zero suppression converts the barcode into a more compact version. This
offers the possibility to key in up to 12 characters which are compressed into 6
characters by the printer. Inthis case the first character must be zero !!
Detailed information is available by the UCC, Inc ( Uniform Code Council, Inc.)
B[:Name;]x,y,r,UPCE0,height,ne;text
CR
B - Barcode field definition
[:name;] = field name
x = x - coordinate
y = y - coordinate
r = Rotation 0, 90, 180 and 270 degrees
type = Barcode type (UPCE0)
[+options] Following options are available:
+WSarea = white space area
+BARS = Prints boundary lines above and below the barcode.
+UPBAR = Prints a boundary line above the barcode
+DOWNBAR = Prints a boundary line below the barcode
+VERIFYn = Verify the barcode data. (optional barcode reader required )
+GOODBADn = Same function as +VERIFYn without checking the content.
height = Barcode height
ne = Narrow element
ratio = Ratio between narrow and wide bars.
text = Barcode data
Detailed descriptions are at the beginning of the barcode chapter.
Syntax:
