G - Graphic Definition - Rectangle
Graphic Type: R - Rectangle
G[:name;]x,y,r;R:width,height[,ht [,vt]][,options] CR
G = Graphic field definition command.
[:name;] = Optional field name. Maximum length 10 characters, no special
characters allowed, field name must be unique. The field name
can be used for further operations, such as Replace field name
(See the „R“ command for details) or just as a comment.
x = Horizontal coordinate of the start position in millimeters or
inches from the left edge of the printable area to the start point
of the rectangle.
y = Vertical coordinate of the start position in millimeters or inches
from the left edge of the printable area to the start point of the
rectangle.
Starting point of rectangles is the upper left corner, outside of
the rectangle
r = Rotation.Rectangles can be rotated in steps of 1degrees
from 0 to 359 degrees.
R = Rectangle
width = width (horizontal ) of the rectangle in millimeters or inches
height = height (vertical) of the rectangle in millimeters or inches
ht = horizontal line thickness in millimeters or inches
vt = vertical line thickness in millimeters or inches
Filled rectangles are printed, if "width" is not set.
