G - Graphic Definition - Circle
Graphic Type: C - Circle, Ellipse
G[:name;]x,y,r;C:radius1[,radius2[,width]][,options]
CR
G = Graphic field definition command.
[:name;] = Optional field name. Maximum length 10 characters, no special
characters allowed, field name must be unique. The field name
can be used for further operations, such as Replace field name
(See the „R“ command for details) or just as a comment.
x = Horizontal coordinate of the start position in millimeters or
inches from the left edge of the printable area to the center of
the circle.
y = Vertical coordinate of the start position in millimeters or inches
from the left edge of the printable area to the center of the
circle.
Starting point of Circles or Ellipses is in the center
r = Rotation.Circles and ellipses can be rotated in steps of 1degrees
from 0 to 359 degrees. This makes for sure less sense for
circles. Visible effects can be seen on ellipses...
C = Circle
radius1 = horizontal radius
radius1 = vertical radius
width = width of the circle line in millimeters or inches
Filled circles or ellipses can be printed if the width is not set
continued on the next page
