cab Produkttechnik GmbH & Co KG
ESC
i
Send value from the
I
NF-memory
ESCi responds the last value of the INF memory
.This can be used to get the value of the last printed
label. The value uses the actual selected codepage and is finished with a carriage Return.
For more details please view the
[WINF]
command, which writes to the INF memory - described in the
section of „S
pecial commands“
ESCi
Syntax:
45
47
