S - Set Label Size
This command defines the width and length of a label and has some additional options.
S[ptype;]xo,yo,ho,dy,wd[,dx,col][;name]
CR
S - Set label size
ptype; = photocell type. Sets the type of label sensing. Optional parameter.
It is recommended to set it in the label definition.
e = endless (continuous) label material without die cuts. Labels
sensor is switched off and the height is measured by the
amount of micro steps of the printer´s transport motor.
Important: the following character is a lower case L followed
either by 0,1 or 2 !!
l0 = senses the reflective marker on the upper side of the label
material. ( only if the printer is equipped with this sensor!!!)
( l0 = small letter L + 0)
l1 = sets the printer´s sensors for die cut labels with gap.
( l1 = small letter L + 1)
l2 = senses the reflective marker on the lower side of the label
material. ( l2 = small letter L + 2)
xo = horizontal displacement, shifts the starting point (zero point) of all
horizontal measurements to the left margin of the label.
yo = vertical displacement, shifts the starting point (zero point) of all
vertical measurements to the top margin of the label.
ho = height of the label in transportation direction.
dy = height of the label plus height of the gap. (Distance from the
starting point of the first label to the starting point of the next label)
wd = label width measured from the right margin to the left margin.
continued on the next page....
