Example:
G - Graphic Definition - Option: Outline
Graphic Option: Outline
Prints an outline around the filled graphic object with the thickness of 1 dot.
G[:name;]x,y,r;type:type options [shade options][O] CR
The outline option outlines filled objects. The outline option prints black objects, if
outline [O] is used for objects which are not filled. (see sample on the next page)
[O] = Outline
m m
J
S l1;0,0,68,71,100
G 5,20,0;R:20,20,1,20[S:60,10,45][O]
G 85,30,0;C:10,10,10,10[S:60,10,75][O]
G 10,10,0;L:80,2[S:30][O]
A 1
Syntax:
