G - Graphic Definition - Line
Graphic Type: L - Line
G[:name;]x,y,r;L:length,width[,start[,end]][,options] CR
G = Graphic field definition command.
[:name;] = Optional field name. Maximum length 10 characters, no special
characters allowed, field name must be unique. The field name
can be used for further operations, such as Replace field name
(See the „R“ command for details) or just as a comment.
x = Horizontal coordinate of the start position in millimeters or inches
from the left edge of the printable area to the start point of the line
y = Vertical coordinate of the start position in millimeters or inches
from the left edge of the printable area to the start point of the line
Starting point of Lines is the center of the starting point of the line
r = Rotation.Lines can be rotated in steps of 1degrees from 0 to 359
degrees.
L = Line
length = length of the line in millimeters or inches
width = width of the line in millimeters or inches
start = line start type.
s= squared
r=rounded
a=arrowed
end = line end type
s= squared
r=rounded
a=arrowed
Lines will print squared without the start / end parameters
