cab Produkttechnik GmbH & Co KG
ESC
*
Activate all RS-485 printers
Activates all printers in a RS-485 network at the same time.
ESC*
Sends the following data to all attached printers at the same time.
This function is only available for
printers which are (optional) equipped with the RS485 interface.
Please note that this optional interface hardware is not available for all label printing systems.
Syntax:
35
37
