B - Barcode EAN-13 / JAN-13
Barcode type: EAN-13 / JAN-13 (European / Japanese Article Numbering)
Length: fixed - 13 digits
Valid characters: numeric,
digits: 0-9,
check digits: yes
ratio oriented: no
The EAN 13 code is used in retail environment in Europe with a fixed length of 13
digits. The 13th digit contains the calculated checksum. cab printers expect 12
digits, while the 13th digit is calculated by the printer.
JAN 13 is the japanese version of EAN 13.
B[:name;]x,y,r,EAN13[+options],height,ne;text CR
B - Barcode field definition
[:name;] = field name
x = x - coordinate
y = y - coordinate
r = Rotation 0, 90, 180 and 270 degrees
type = Barcode type (EAN13)
[+options] Following options are available:
+WSarea = white space area
+BARS = Prints boundary lines above and below the barcode.
+UPBAR = Prints a boundary line above the barcode
+XHRI = (Extended Human Readable Interpretation
+VERIFYn = Verify the barcode data. (optional barcode reader required )
+GOODBADn = Same function as +VERIFYn without checking the content.
size = Standard Codesize SCx (instead of height and ne)
height = Barcode height
ne = Narrow element
text = Barcode data
Detailed descriptions are at the beginning of the barcode chapter.
Syntax:
