90cab Produkttechnik GmbH & Co KG
x - Synchronous Peripheral Signal Settings
The signal bits of the peripheral connector for external connections can be set with this command.
Usage: Together with an optional adapter with electrical protected interface.
The availability of these adapters depends on the used printing system.
IMPORTANT: Never connect any non cab item directly to the printers auxiliary interface !
In all cases you will need an optional adapter with the required interface !!!
Connections directly on the auxiliary interface may damage the printer electronics !
The auxiliary interface does not deliver the following signals directly.
This command controls the status of the output pins. The x command was added to take control over
peripheral device, which is usually other than the offered cab equipment. The four signal bits can be set
as follows:
Control bit 0, set on when a label starts printing
Control bit 1, toggled when a new print job starts
Control bit 2, set on for error
Control bit 3, set on when label is in the peel-off position
Each of these bits can be set or reset for individual needs. The bit signals can be used to control
external - non cab - devices.
To reset all of these bits, use ESC!ESC! (see ESC commands)
x m;m
CR
x - Snchronous Peripheral Signal Setting Command
m = Mask (hex nibble).
The usage of this command depends on the printer type. The description of the pin assignment can be
found in the available documentation for the optional adapters
Syntax:
