B - Barcode MSI (MSI Plessey)
Barcode type: MSI (MSI Plessey)
Length: variable
Valid characters: numeric,
check digits: yes (Mod 10)
ratio oriented: yes
The MSI Plessey code is a numeric barcode with variable length and a modulo 10
check digit which is automatically added by the printer. Additional modulo check
digits can be added to this code.
B[:name;]x,y,r,MSI[+options],height,ne,ratio;text CR
B - Barcode field definition
[:name;] = field name
x = x - coordinate
y = y - coordinate
r = Rotation 0, 90, 180 and 270 degrees
type = Barcode type (MSI)
[+options] Following options are available:
+MODxx = calculation of modulo check digit (MOD10 and MOD11)
+WSarea = white space area
+BARS = Prints boundary lines above and below the barcode.
+UPBAR = Prints a boundary line above the barcode
+DOWNBAR = Prints a boundary line below the barcode
+VERIFYn = Verify the barcode data. (optional barcode reader required )
+GOODBADn = Same function as +VERIFYn without checking the content.
height = Barcode height
ne = Narrow element
ratio = Ratio between narrow and wide bars.
text = Barcode data
Detailed descriptions are at the beginning of the barcode chapter.
Syntax:
