cab Produkttechnik GmbH & Co KG
B - Barcode
Code 93
m m
J
S l1;0,0,68,71,100
B 25, 5,0,
CODE93
+XHRI,16,0.28,3;ABC123
B 25,24,0,
code93
,16,0.28,3;ABC123
B 25,44,0,
CODE93
+BARS,16,0.28,3;ABC123
A 1
Example:
122
124
