B - Barcode Plessey
Barcode type: Plessey
Length: variable
Valid characters: A-F and 0-9
check digits: no
ratio oriented: yes
Plessey Barcode is a seldom used barcode which encoding possibilities are
limited, as only numbers and 6 characters are encoded
B[:name;]x,y,r,PLESSEY[+options],height,ne,ratio;text CR
B - Barcode field definition
[:name;] = field name
x = x - coordinate
y = y - coordinate
r = Rotation 0, 90, 180 and 270 degrees
type = Barcode type (PLESSEY)
[+options] Following options are available:
+WSarea = white space area
+BARS = Prints boundary lines above and below the barcode.
+UPBAR = Prints a boundary line above the barcode
+DOWNBAR = Prints a boundary line below the barcode
+VERIFYn = Verify the barcode data. (optional barcode reader required )
+GOODBADn = Same function as +VERIFYn without checking the content.
height = Barcode height
ne = Narrow element
ratio = Ratio between narrow and wide bars.
text = Barcode data
Detailed descriptions are at the beginning of the barcode chapter.
