cab Produkttechnik GmbH & Co KG
Example:
B - Barcode
RSS-14 composite (CC-A)
m m
J
S l1;0,0,68,71,104
T 5,10,0,5,5;RSS-14 composite (CC-A)
B 10,15,0,
RSS14
,16.5,.5;0361234567890[U:2D](11)990102
A 1
166
168
