cab Produkttechnik GmbH & Co KG
Example:
B - Barcode
RSS-14 st
acked
m m
J
S l1;0,0,68,71,104
T 5,10,0,5,5;RSS-14 stacked
B 10,15,0,
RSS14+STACKED
,12,0.5;0001234567890
A 1
176
178
