cab Produkttechnik GmbH & Co KG
B - Barcode
RSS-14 st
acked composite (CC-A)
m m
J
S l1;0,0,68,71,104
T 5,10,0,5,5;RSS-14 stacked composite CC-A
B 10,15,0,
RSS14+STACKED
,12,0.5;0341234567890
[U:2D](17)010200
A 1
Example:
178
180
