cab Produkttechnik GmbH & Co KG
B - Barcode
RSS exp
anded
m m
J
S l1;0,0,68,71,104
T 5,10,0,5,5;RSS expanded
B10,15,0,
RSSEXPANDED
,10,.3;(01)98898765432106(3202)012345(15)991231
A 1
Example:
194
196
