cab Produkttechnik GmbH & Co KG
B - Barcode
RSS exp
anded composite (CC-A)
m m
J
S l1;0,0,68,71,104
T 5,10,0,5,5;RSS expanded composite CC-A
B
10,15,0,
RSSEXPANDED
,16.5,.5;(01)93712345678904(3103)001234[U:2D](91)1A2B3C4D5E
A 1
Example:
196
198
