288
288
288
cab Produkttechnik GmbH & Co KG
Example:
Date Functions
[DA
TE... ] Print actual
DA
TE
m m
J
S l1;0,0,68,71,100
T 3,25,0,3,6;In 10 Years we have:
[DATE:03,02,10]
A1
This example adds 3 days, 2 months and 10 years
287
289
