cab Produkttechnik GmbH & Co KG
S
pecial Content Fields
S
pecial Barcode functions (not supported by all barcodes)
[ECE: 123456]
Adds information for extended channel to barcodes
[APPEND:m,n,id1,id2]
[APPEND:x,id]
Adds information for linked barcodes
[ANSI_DI]
Adds information for
ANSI - data identifier
[ANSI_AI]
Adds information for
ANSI - application identifier
