Special Functions
Example:
[SER:...] - Serial numbering
The following example shows a label which will be saved on the printers memory card and the variable
start value is sent by the attached computer.
Please refer also to the "M s“ command which explains how to save labels on a memory card.
Ms LBL;NUMBER
m m
J
H 100,0
S l1;.0,.0,50.0,53.5,70.0
T:YEAR;60.3,4.8,180.0,5,4.0;[YYYY]
T:NR;0,0,0,3,2;0000000[I]
T:OS;0,0,0,3,2;[SER:0000000][I]
T:SER;48.3,4.7,180.0,5,4.0;[+:NR,OS][C:0][D:7,0]
B:BAR2;66.7,43.9,180.0,2of5interleaved+MOD10,35.0,.34,3.0;[YEAR][SER]
B:BAR3;19.9,6.0,270.0,2of5interleaved+MOD10,18.0,.34,3.0;[BAR2]
Ms LBL
A 1[NOPRINT]
Ml LBL;NUMBER
R OS;[SER:0000025]
A 3
The Ml command recalls the label,the R command replaces the variable "OS“ and the printer prints 3
labels.
