cab Produkttechnik GmbH & Co KG
The connection can be keyed in manually if it is known for the database connection or the built in
wizard may be called up which appears in on screen as shown below
.
Details about the wizard are described in the built in help file.
Y
ou need good knowledge about your
data base do a proper setup !
cab Database connector can be started multiple times in a network or multiple times on one PC.
cab Dat
aBase Connector
393
395
