t - Run Printer Self-
t
est
t3
produces following result after the printer feeded a few empty labels for the
measurement process.
( Label profile )
t5
prints a text grid which can be used for the printhead adjustment or to control the print
quality of the printer
.
( T
estgrid )
Example:
Example:
86
88
