8-22
You edit chords in the Chord Properties dialog box. Chord properties are
shown in the following table:
The Chord Properties dialog box also lets you draw guitar chord grids
and manage the chord library.
You can suppress the display of all guitar chord diagrams by deselecting
the Show Chord Grids option in the Staff view's Layout dialog box. With
this option disabled, only chord text appears.
Property... Meaning...
Time The time of the chord, in measure, beat, and tick
(MBT) format
Name The name of the chord
Group The chord group
To Add a Chord Symbol...
1. Click the Draw tool .
2. Select the Chord tool .
3. Position the pointer above the staff (the pointer changes to a
pencil when you are in a legal position).
4. Click to place a chord symbol.
Pro Audio inserts a copy of the most recently added chord (by default,
C). You can then edit the symbol to display the chord you want.
To Move a Chord Symbol...
1. Click the Draw tool .
2. Drag the chord symbol to a new location.
