Case 1121F - Page 105

3-CONTROLSANDINSTRUMENTS
8.Transmissionoiltemperaturegauge
Thetransmissionoiltemperaturegauge
indicatestheoiltemperatureofthe
transmission.
TheCautionMasterIndicatorisanon-criticalwarningdis-
play.SeeNon-CriticalWarningDisplays.
Thenormaloperatingtemperatureisinthegreenzone.
Whenthetransmissionoiltemperatureincreases,the
gaugewillmoveintotheyellowzone,thewarningalarm
sounds,andthecautionmasterindicatorturnsyellow.
Whenthetemperaturecontinuestoincreasethegauge
movesintotheredzone,thewarningalarmwillsound
continuously,andthestopmasterindicatorturnsred.Do
notoperatethemachinewhenthetemperatureisinthe
redzone.
RCPH10WHL008AAD3
Transmissionoiltemperaturegauge
GaugeindicationCondition
Master
indicator
Gaugestatus
Alarmstatus
20°C
(68°F)andbelow
OiltemperatureisverylowCaution(yellow)
Flashes
3Seconds
20-120°C
(68-248°F)
Oiltemperatureisnormal
120-125°C
(248-257°F)
(Seethenotebelow.)
OiltemperatureishighCaution(yellow)
Flashes
3Seconds
125°C
(257°F)andabove
OiltemperatureisveryhighStop(red)
Flashes
Continuous
NOTE:Topreventdamagetothetransmission,stopthemachine,shiftthetransmissiontoneutral,andruntheengine
atpartialthrottle(approximately1700RPM)untilthetransmissioncools.Ifthetransmissionoiltemperaturedoesnot
returntonormaloperatingtemperature,runtheengineatidlespeed,andcheckthetransmissionoillevel.Correct
theproblembeforecontinuingtooperatethemachine.
