3-CONTROLSANDINSTRUMENTS
RCPH10WHL001FAD4
9.Hydraulicoiltemperaturegauge
Thehydraulicoiltemperaturegauge
indicatestheoiltemperatureofthe
hydraulicsystem.Normaloperating
temperatureisinthegreenzone.When
thehydraulicoiltemperatureincreasesthe
gaugewillmoveintotheyellowzone,the
warningalarmsoundsforthreeseconds,
andthecautionmasterindicatorturns
yellow.Whenthetemperaturecontinuesto
increasethegaugemovesintotheredzone
andthewarningalarmsoundscontinuously.
Thestopmasterindicatorturnsred.Donot
operatethemachinewhenthetemperature
isintheredzone.
RCIL10WHL180BAL5
Hydraulicoiltemperaturegauge
GaugeindicationCondition
Masterindicator
GaugeStatusAlarmStatus
20°C
(68°F)andbelow
Hydraulicoiltemperatureisverylow
Caution(yellow)
Flashes
3Seconds
20-105°C
(68-221°F)
Hydraulicoiltemperatureisnormal
105-110°C
(221-230°F)
(Seethenotebelow.)
Hydraulicoiltemperatureishigh
Caution(yellow)
Flashes
3Seconds
110°C
(230°F)andabove
Hydraulicoiltemperatureveryhigh
Stop(red)
Flashes
Continuous
NOTE:Donotoperatethemachineiftheindicatorturnsredandthealarmsoundscontinuously.Stopthemachine
andcorrecttheproblem.
3-40
