3-CONTROLSANDINSTRUMENTS
RCPH10WHL001FAD6
10.Fuellevelgauge
Thefuellevelgaugeindicatesthefuel
level.Normaloperatingrangeisinthe
greenzone.Whenthetankisalmostempty
thegaugewillmoveintotheyellowzone
andthefuelindicatorwillturnonandthe
warningalarmwillsound.
NOTICE:Donotallowthemachinetoruncompletelyout
offuel.
RCIL10WHL180BAL7
Fuellevelgauge
GaugeindicationCondition
Masterindicator
Gaugestatus
Alarmstatus
10%andbelow
Fuellevellow
Caution(yellow)ON3Seconds
10%andabove
Fuellevelnormal
WARNING
Pressurizedhydraulicuidcanpenetratetheskinandcausesevereinjuries.
Ifthemachinerunsoutoffuel,donotattempttoworkonpressurizedhydrauliclines.Linesareunder
highpressure.
Failuretocomplycouldresultindeathorseriousinjury.
W0372A
