Forward,neutral,reverse(F-N-R)Switch
A.Forward
B.Neutral
C.Reverse
AnF-N-R(forward-neutral-reverse)switchislocatedon
theleftarmrestasaconveniencefeaturewhenusingthe
joysticksteeringoption.Thefeaturesandfunctionsofthe
switchareidenticaltothestandardF-N-Rswitch.This
F-N-Rswitchisonlyactivewhenthejoysticksteeringhas
beenactivated.
ToactuatethearmrestF-N-Rswitchthefollowingcondi-
tionsMUSTbemet:
1.Themachinemustbestopped.
2.Theenginemustberunning.
3.ThearmrestF-N-Rswitchmustbeinneutral.
4.Thestandardtransmissioncontrollevermustbein
neutral.
5.Theparkingbrakemustbereleased.
NOTICE:Thegearshiftleverlocatedonthesteeringcol-
umnalwayshaspriority.
RCIL10WHL189BAL14
Kick-downswitch
Thekickdownswitchisusedtoshiftdownthroughthe
gearsinsinglesteps.Eachtimetheswitchispressed,
thetransmissionwillshiftdownonegearrangeuntilrst
gearisreached.Oncethekickdownswitchhasbeen
presseddown,thetransmissionmaximumgearallowed
islowered.Itwillreturntotheautomaticmodewhenthe
transmissioncontrollevergearchanges,orthetransmis-
sioncontrolleverismovedtoNEUTRALandthentoFOR-
WARDortoREVERSE.
WhentheAutomaticModehasbeenchosenbytheop-
erator,theAutomaticModeindicatorwillbeshowninthe
multi-functiondisplay.
RCIL10WHL189BAL15
